TYA-302 Access Control Panel

TYA Tech MW 302 is one of the first products that comes to mind when it comes to access control panel.

This is because they have different effective features.

TYA Tech TYA-302,

  • Ability to connect 2 wiegand readers
  • Ability to store 100,000 card information
  • Ability to keep 150,000 log records
  • Introducing 2048 transition groups

and thanks to its easy-to-use interface, it makes it very easy for you, our customers.

SKU: TYA-302 Categories: ,
Description

TYA-302 Access Control Panel Features

TYA Tech TYA-302 is the result of long R&D research

A 32-bit microprocessor used for access control systems

is the access control panel.

TYA Tech TYA-302 uses TCP-IP technology to connect to other panels and access control systems on the network

It allows you to communicate quickly with other products in it.

A total of 2 TYA Tech or other brand access controllers to the TYA-302 access control panel

card readers and wiegand fingerprint devices can be integrated.

Thanks to the TCP/IP protocol, you can use as many TYA-302s as you want in your system

so you can control an unlimited number of doors.

The most effective feature of the TYA-302 access control panel is that they can communicate among themselves.

TYA-302 without the need for any online software or additional products

all features continue to work actively.

Software Features
TYA-302 Access Control Panel
  • Maximum card memory: 100,000 (Personnel and visitor)
  • Maximum event memory: 150,000
  • Maximum access group: 2048
  • Group-based access settings
  • Real-time clock and date information
  • Ability to work 24/7 while computers or servers are disabled
  • Communication between panels via Ethernet network
  • Group and user-based access settings
  • Limiting access based on date and time ranges
  • Visitor support
  • Easy user interface
  • Local Anti-Passback
  • Global Anti-Passback
Hardware Features
TYA-302 Access Control Panel
  • 2 Wiegand Readers ( TYA Tech TYA-105, HID, other brand EM and Mifare readers can be integrated)
  • 2 Exit Buttons
  • 2 Magnetic Contacts
  • 2 Relay Outputs
  • 1 Alarm Relay Output (To be connected with the alarm system)
  • On-board LED monitoring for each relay output
  • 100 Mbit Ethernet port
  • 2 RS-485 ports
  • 1 RS-232 port
  • All input points are protected with optical isolators
  • 32 bit 60 Mhz CPU + 16 bit Co-processor
  • 1 MB SRAM, 2.5 MB Flash memory
  • 10 years Memory Protection and Real Time Clock with 3V Lithium battery
  • EMC filtering
  • 3.3V, 5V voltage control LED diodes
  • COM and ERR LED diodes
  • 12V DC – 3A 8 reader internal supply
  • NO/NC relay output (maximum 120V AC / 30V DC – 3A relay voltage)
  • Sheet Panel (Special lock for each panel)
  • Power Distribution and Battery Condition circuit, optional 12 V – 7.2 Ah battery.
  • 12 V DC – 5 A main power supply
